DESUN MACHINE TOOL ACCESSORIES

Mo	C	N	O	Fe	Ni	Si
Mo1≥99.95 MoG≥99.35	<0.006	<0.002	<0.003	<0.003	<0.002	<0.002
Remarks: 0.2%-0.6% OF Doped elements in MoG which is not treated as impurity content

　　Product Availability

Product Name	Item No	Specificationsφ (mm)	Single-root weight(kg)	Tolerance (mm)	Elongation (%)	Packing
Wire Cutting Molybdenum Wire	Mo1 MoLa MoK	0.12~0.20	0.390~ 0.680 Or Fixed-length	+0.003 -0.002	1.5~2.5	Precision complex around the bakelite plate and then vacuum package around the complex
Note: Other quality requirements are in line with the GB/T4182-2003, designated in accordance with customers demand.

The table of GB tensile strength and the corresponding pull off force and 30 percent ultra-GB pull off force and the length of the silk in each gram.

Specificationsφ(mm)		0.12	0.13	0.14	0.15	0.16	0.17	0.18	0.20
GB	Tensile strength≥(N/mm2)	1500
GB	Corresponding Pull off force(N)	17.0	19.9	23.1	26.5	30.2	34.1	38.2	47.1
30% of ultra-GB pull off force(N)		23.5	27.6	30.0	34.5	39.2	44.3	49.6	61.3
The length of each gram(m/g)		8.669	7.386	6.369	5.548	4.876	4.319	3.853	3.121
Pay attentions: 385.3 ± 2% each 100g for φ0.18mm molybdenum wire (the impact of tolerance on the length)

Product characteristics and usage

　　With raw material of high-quality article molybdenum, special equipments and unique manufacturing process, the products, with ultra-high strength (ultra-GB 30%), are less likely to be broken during being used, and cutting life is longer. With ree added to the article molybdenum, the processing performance is obviously higher than other similar products. Products are applicable to all types of die steel, carbide, precision cutting of magnetic materials. The finished products are packed with vacuum so as to prevent oxidation of molybdenum wire mildew and be stored for a long time.
